Hybono launched an online ammonia nitrogen sensor (HY560-A), which requires no reagents, is green and pollution-free, and can be monitored online in real time. Integrated ammonium ion, potassium ion, pH and reference electrodes to automatically compensate for potassium ion, pH and temperature in water. It can be directly installed and installed, which is more economical, environmentally friendly, convenient and fast than traditional ammonia nitrogen analyzers. The sensor comes with a self-cleaning brush that prevents the attachment of microorganisms for longer maintenance intervals and reliability. Adopt RS485 output, support Modbus, easy to integrate.
Overview
Hybono NH4-N ISE sensor measures the concentration of dissolved ammonium as nitrogen (NH4-N) in water. The sensor uses pH, Ammonium Ion electrodes, and an optional potassium ion electrode to determine the NH4+-N concentration. It is designed for use in all kind of natural water, such as lakes, streams, rivers, as well as wastewater plants. The online sensor measures ammonium electron concentration without using any chemicals. With automatic wiper to clean up the electrode sensing surface and easy electrode replacement, HY560-A provides a quick, simple, and economical solution for ammonium concentration measurement.
Features
▲RS-485; MODBUS protocol compatible
▲No reagent, no pollutants, more economic and environmentally friendly
▲Automatic compensation for NH4+, pH and temperature in water
▲With a self-cleaning wiper, prevent biofouling to guarantee accurate measurement
| Name | Parameter | |
| Model | HY560-A | |
| NH4_N Range | 0-10mg/L NH4-N | 0-100mg/L NH4-N |
| NH4_N Accuracy | ±（5%+0.2mg/l) | |
| NH4_N Resolution | 0.1 mg/L | |
| pH Range | 4-10PH | |
| pH Accuracy | ±0.1pH | |
| pH Resolution | 0.01 | |
| Housing IP Rating | IP68 | |
| Deepest Depth | 10m underwater | |
| Temperature Range | 0 ~ 50℃ | |
| Interface | Support RS-485， MODBUS protocols | |
| IP Rating | IP68 | |
| Power | DC8~26VDC±10%，current<50mA | |
| Cable Length | 10m standard, Custom length available | |
| Body Materials | POM | |
-
